| 物理 |
| 尺寸 (LxW) |
90x36mm |
| 工作温度 |
-40ºC ... +55ºC |
| IP保护等级 |
IP20 |
| 湿度 |
10 - 95% non-condensing (VDE 0110) |
| SoC |
| 处理器 |
Nordic Semiconductor nRF52832 |
| 处理器核 |
Cortex-M4F |
| MPU速度 |
64 MHz |
| 存储器 |
| RAM |
64 kB on-chip |
| 保存 |
512 kB Flash on-chip |
| 电源 |
| 电池 |
2x CR2477 |
| 24V供电 |
9...28V |
| 连接性 |
| 无线电 |
2.4 GHz收发器带外部天线 (RP-SMA receptable) |
| NFC |
NFC-A Tag Emulation for Mesh Network Provisioning |
| 背板 |
1 (可选扩展) |
| I2C |
1 (可选扩展) |
|
| I/O接口 |
| 数字输入24VDC |
2 (high-side) |
| 模拟输入(电压) |
1 (0...10 VDC) |
| 模拟输入(电流) |
1 (0...20mA) |
| 数字输出24VDC, 0,5A |
1 (low-side) |
| 继电器30VDC, 1A |
1 (2-coil latching) |
| 软件 |
| 固件 |
Application with Wirepas Mesh |
| 固件升级 |
Over-the-air |
| 控制 |
| 状态LEDs |
Power 24VDC |
| |
Status DI 24VDC |
| |
Software Status |
订货信息
| 货号 |
说明 |
| 18051000 |
sysWORXX SRN-300 with external antenna |
18051010 |
sysWORXX SRN-300 with integrated antenna |
|
